Actuators
Showing 1–12 of 51 results
-
Ball Screw Driven Series
Read moreThe MTV series ballscrew actuator strikes a great balance between price and performance and is able to meet the requirements of high-precision and high-thrust applications of many kinds.
-
Belt Driven Series
Read moreThe Belt Driven Linear Unit series with toothed belt drives and compact dimensions provide high performance features such as, high speed, good accuracy and repeatability.
Additional Add-ons:
- Fixing System
- Centering Rings
- Magnetic Field Sensors
-
CTJ
Read moreA compact linear unit with an AT toothed belt with steel cords and two parallel, integrated zero-clearance guide rail systems.
-
HexaLift
Read morePush Force Max: 3200N
Speed (without load): 9mm/s
Retracted Length (standard) :530/580/630/680mm
Stroke Standard: 350/400/450/500mm
Voltage: 24VDC
Cycle Duty: 1/9 (10%) min
Integrated End Switches (Yes) -
IMI Norgren DLT/DLK Linear Axis
Read moreSpindle driven Linear Axis range with a rectangular, Aluminum profile.
- Twin integrated rail guides ensure this range is suitable for applications handling exceptionally heavy loads
- The carriage is driven by means of a rotating spindle with leading nut
- The leading-nut receiver can be used to adjust the symmetry of the carriages where two linear units are used in parallel or where twin carriages are mounted
- Openings in the guide body are sealed with stainless steel cover bands providing protection against splash water and dust ingress
For Standard Industrial Applications
-
IMI Norgren DLZA Linear Axis
Read moreRack and Pinion driven Linear Axis range with a rectangular Aluminum profile and integrated, hardened steel guide rods.
- Twin integrated roller guides ensure this range is suited to heavy duty applications with heavy loads
- The carriage runs on internal linear ball bearings that can be adjusted free of play and is driven along the guide rods by a high precision rack
- The pinion is equipped with maintenance-free ball bearings
- The rack and pinion system is suitable for highly dynamic servo operation and ideal for lifting applications
- Multiple units can be assembled in series to achieve extended strokes
For Heavy Duty Industrial Applications
-
IMI Norgren DST/DSK Linear Axis
Read moreSpindle driven Linear Axis with a rectangular, Aluminum profile.
- Twin integrated rail guides ensure this range is suitable for applications handling exceptionally heavy loads
- The carriage is driven by means of a rotating spindle with leading nut
- The leading-nut receiver can be used to adjust the symmetry of the carriages where two linear units are used in parallel or where twin carriages are mounted
- The openings of the guide body are sealed with stainless steel cover bands providing protection against splash water and dust ingress (cover bands are optional)
For Heavy Duty Industrial Applications
-
IMI Norgren DSZA Linear Axis
Read moreRack and Pinion driven Linear Axis range with a rectangular Aluminum profile and integrated, hardened steel guide rods.
- Twin integrated rail guides ensure this range is suited to
heavy duty applications with heavy loads - The carriage is driven by a pinion on a high precision rack
- The pinion is equipped with maintenance-free ball bearings
- The rack and pinion system is suitable for highly dynamic servo operation and ideal for lifting applications
- Multiple units can be assembled in series to achieve extended strokes
For Heavy Duty Industrial Applications
- Twin integrated rail guides ensure this range is suited to
-
IMI Norgren EGT/EGK Linear Axis
Read moreSpindle driven Linear Axis range with a square, Aluminum profile and sliding guides.
- The carriage is driven by means of a trapezoidal/ball screw threaded spindle with lead screw
- Guided by lateral V-slides that are adjustable free of play
- The linear opening of the unit is sealed with a stainless steel strip providing protection against splash water and dust ingress
- The leading-nut receiver can be used to adjust the symmetry of the carriages where two linear units are used in parallel or where twin carriages are mounted
For Standard Industrial Applications
-
IMI Norgren ELSZ Linear Axis
Read moreToothbelt driven Linear Axis range with a square, Aluminum profile and hardened Steel guide rods.
- Omega belt system provides flexibility with mounting, making this range ideally suited for vertical installations
- The carriage runs on internal linear ball bearings that can be adjusted free of play
- The pulleys have maintenance-free ball bearings
- Belt tension is adjusted via simple screw adjustment device in carriage
- Alternative versions available with widened belt for higher load capacity
For Standard Industrial Applications
-
IMI Norgren ELT/ELK Linear Axis
Read moreSpindle driven Linear Axis range with a square, Aluminum hollow section with integrated, parallel, ground and hardened Steel guide rods.
- The carriage is driven by a rotating trapezoidal/ball screw threaded spindle connected to the carriage by a ball nut
- The carriage has play-adjustable ball-bearing rollers which engage with the guide rods
- The connecting slot between carriage and ball nut is covered by a stainless steel strip providing protection against splash water and dust ingress
- Lateral adjustment of movement for parallel units, or where twin carriages are mounted, is provided by the ball nut mounting
For Standard Industrial Applications
-
IMI Norgren ELZ Linear Axis
Read moreTooth belt driven Linear Axis range with a square, Aluminum profile and integrated hardened Steel guide rods.
- The carriage runs on internal linear ball bearings that can be adjusted free of play
- The pulleys have maintenance-free ball bearings
- Belt tension is adjusted via simple screw adjustment device in carriage
- Multiple units can be assembled in series to achieve extended strokes
- Carriage can be customized to include extensions and accessories mounted within the profile
- NORDKAP certified and ATEX rated versions available
For Standard Industrial Applications
